API/BS1873 Globe Valve Series



API/BS1873 Globe Valve Series

Applicable/Product Standards:
Steel Globe Design: API 600 / BS1873
Steel Valves: ASME B16.34
Face to Face according to: ASME B16.10
Flanges Ends according to: ASME B16.5
Butt Welding Ends according to: ASME B16.25
Inspection and Testing according to: API 598 / API 6D

Design/Production Description:
·Meet design requirements of ANSI B16.5, B16.34, B16.10
  B16.25 (for NPS≤24), MSS SP-44(for NPS>24), API-600
-Straight and Y patteren body design
-OS & Y,outside screw and yoke
-BB,Bolted bonnet
-Yoke intergral with bonnet
-Rising stem and handwheel
-Loose disc,choice of plug or ball
-Renewable seat ring or Body seat ring
-Impact handwheel for 10" & above
-Horizontal servece
-Flanged or buttwelding ends





WINDMILL Globe Valve Feature:

Full Port Design / Globe Stop Design
OS&Y,Outside Screw and Yoke
BB,Bolted Bonnet
Or PSB,Pressure Seal Bonnet
Switt Disc, Fully Guided
Size: 2"-20"
Pressure: 150LB,300LB,600LB,900LB,1500LB,2500LB
Connection: Flanges,RTJ Flange,Butt Weld,Groove
Material:
Carbon Steel, Forged Steel, Stainless Steel: WCB,LCB,LCC,LC1,CF8,CF8M,CF3,CF3M,WC6,WC9, C5,C12,C12A
Specifical Material:
Duplex Steel, Super Duplex Steel, Inconel: GR4A, GR6A, CY-40, Inconel 600
Operate: Handwheel, Wormgear, Gearbox, Penumatic Actuator, Electric  Actuator, Hydraulic Actuator.
